Low profile Ceiling Lift suitable for false ceilings with small inner height and projectors up to 14kg
. PLC V5.2 is characterized by excellent utility, great stability and great accuracy in up and down position.
Ideal for use in false ceilings with tile dimensions ≥600x600mm.
Low profile Ceiling Lift suitable for false ceilings with small inner height and projectors up to 14kg
. PLC V5.2 is characterized by excellent utility, great stability and great accuracy in up and down position.
Ideal for use in false ceilings with tile dimensions ≥600x600mm.
0 çååú ãòú
( çååú ãòú âåìùéí)
-
éöøï: UNITECH SYSTEMS
-
î÷è: 1393
ìéòåõ àéùé ðéúï ìôðåú àìéðå ìèìôåï 04-6555563
÷åð÷èåø äçéáåø ìòåìí îàåùø
Features
- Slim lift with lowest height possible (from 8cm + projector height)
- Vertical motion with the use of multiple scissors
- Multiple options in stop position
- Great accuracy in up and down position
- Smoth motion
- Easy dismounting and mounting of projector for maintenance purposes
- Silent operation
- Optional remote control
- Choice of color
Specifications
- Maximum load capacity (projector+ceiling cover) up to 20kg
- Maximum projector dimensions within the lift size (WxD) ≤420x440mm
- Lift dimensions (WxHxD):
- 526x(80+projector height for max.projector dept <345mm)x440mm
- 526x(95+projector height for max.projector dept >345mm)x440mm
- Lift weight: ~15kg
- Minimum ceiling hole required: 560x480mm
- Standard run length:
- 175mm for max.projector dept >345mm
- 190mm for max.projector dept <345mm
- Optional run length increase by +175mm each time, for maximum 2 times, with lift height increase by 60mm each time
- Power supply 230VAC/50Hz
